F-1005-XT90 DC Power Fused Distribution Block Module, 40A 58V, Screw or DIN Rail Mounting

Features:
1. DC Power Fused Distribution Block – F-1005-XT90
The F-1005-XT90 DC Power Fused Distribution Block is designed for reliable DC power distribution in robotics, battery testing, industrial automation, energy storage, and other low-voltage power applications. Features one fused power input and eight individually fused output channels for organized and protected power distribution.

2. 40A Total Rated Current, 58V DC Maximum Voltage
Supports a maximum total current of 40A and an operating voltage of up to 58V DC. Distributes power from a common DC source to multiple devices through eight independently fused output channels. The 40A rating applies to the entire module, not to each individual output. Ensure the combined load current does not exceed the module's rated capacity.

3. Power Indicator and Individual Fuse Fault LEDs
Features a power indicator LED and individual fault indicator LEDs for all nine fuses, including one input fuse and eight output fuses, allowing convenient visual monitoring of power status and fuse faults. High-quality fuse holders provide easy front-access fuse replacement without disassembling the enclosure. Compatible with widely available ATC/ATO automotive blade fuses rated from 1A to 40A. All factory-installed fuses are rated for 58V DC. The module comes with one 40A input fuse and eight output fuses: two 30A, two 20A, two 10A, one 5A, and one 3A fuse.

4. Genuine AMASS XT90 Connectors – Secure and Reliable Connections
Equipped with genuine AMASS Electronics XT90PB-F/M and XT90H-F/M connectors, offering low contact resistance and secure mating connections. Designed for reliable electrical connections in vibration-prone environments, including robotics, battery testing, and high-impact testing applications. The XT90H connectors feature protective back covers for improved insulation around soldered wire connections.

5. Durable Aluminum Enclosure with Multiple Mounting Options
Features a durable 1.5mm (0.06-inch) thick aluminum enclosure for a sturdy mounting structure. Supports screw mounting to wood panels, wall mounting, and DIN rail mounting. The included DIN rail mounting adapters are compatible with 15mm, 32mm, and 35mm DIN rails, providing flexible installation options for industrial control panels, equipment enclosures, and workbenches.

6. Complete Connector and Mounting Kit Included
Package includes 1 × F-1005-XT90 power distribution module, 4 × mounting screws, 1 pair of DIN rail mounting adapter brackets, 1 set of XT90H female connectors with back covers, and 8 sets of XT90H male connectors with back covers. The included XT90 connectors require soldering to wires before use. 10 AWG wire is recommended for reliable power connections. The connector kit allows users to prepare custom wiring according to their installation requirements.
