Features:
1. DC Power Distribution Module – D-1739GP.
D-1739GP DC Power Distribution Block Module, designed for reliable DC power distribution in robotics, battery testing, industrial automation, and other low-voltage power applications.
2. 45A Rated Current, 60V Maximum Voltage.
Supports a total input or output current of up to 45A and a maximum operating voltage of 60V DC. Suitable for distributing DC power to multiple devices from a common power source. Ensure the total current across all connections does not exceed the rated limit.
3. Genuine AMASS XT90 Connectors – Secure and Reliable Connections.
Equipped with genuine AMASS Electronics XT90PB-F/M and XT90H-F/M connectors, featuring low contact resistance and secure mating connections. Designed to provide reliable electrical contact in vibration-prone and high-impact testing environments.
4. Durable Materials for Reliable Performance.
Built with an FR-4 fiberglass PCB, a PC (polycarbonate) mounting base, and 304 stainless steel screws. These materials provide a durable mounting structure for industrial and electronic applications.
5. Complete Connector Kit Included.
Includes 1 × D-1739GP module, 2 × mounting screws, 1 set of XT90H female connectors with back covers, and 4 sets of XT90H male connectors with back covers. The included XT90 connectors require soldering to wires before use. 10 AWG wire is recommended for reliable power connections.
